LED Indoor Lighting

LED High Bay Light Winner Series

Heat sink for aluminium alloy with powder spraying process. Anti-corrosion,no toxicity or pollution.
USA Bridgelux chip,from TOP 5 LED chip manufacturer,delivering high luminous efficiency up to 200lm/w
Accurate engineered lens made of optical grade polycarbonate,light transmittance >98%.
Multiple brackets improving installation time.
The steel safety rope offer double protection.
Ready for smart system. 0-10V,PWM,Microwave motion sensor available

Send Inquiry Chat now

LED High Bay Light Winner Series Spec.:

Model	CS-WI-60	CS-WI-80	CS-WI-100	CS-WI-120	CS-WI-150	CS-WI-200
Power	60W	80W	100W	120W	150W	200W
Input Voltage	AC 90-305V 50/60Hz
LEDs	5050 LED
CRI	＞70(>80,>90 optional)
CCT	3000K/4000/5000K/5500K
Beam Angle	60°/90°/120°
Luminous Efficiency	165lm/w	160lm/w	160lm/w	160lm/w	160lm/w	160lm/w
Luminous Flux	9900lm	12800lm	16000lm	19200lm	24000lm	32000lm
LEDs Qty.	72pcs	72pcs	72pcs	78pcs	80pcs	120pcs
IP Rate	IP65
Working Environment	-40℃~50℃,20%~90% H.R
Storage Temperature	-40℃~85℃,10%~90% H.R.
Body Material	Aluminum
Lens Material	PC
Dimmable	0-10V,PWM,Microwave motion sensor
N.W.	2.5KG			3.3KG		3.55KG
Lamp Size(mm)	Ø273x182mm			Ø273x192.5mm		Ø308x202mm
Lifespan	>50,000 Hours (Ta=30℃@L70)
