LED is applied in all walks of life with its own advantages, airport lighting is no exception, so what is the airport lighting standard? How to choose airport lighting fixtures? So here's a little bit of an explanation of the problem of airport lighting design.

The longitudinal spacing of the side lights should not be greater than 60 m, such as the use of the side lights of the side side of the slide reflective markers instead of the side lights, the longitudinal spacing should be 30 m; However, the taxiway sidelight should not be greater than 30 m when set at the edge of the runway u-bend. In the taxiway short straight section, turn and branch of the side lights should be properly reduced. Taxiway sideslip lights shall be located outside the taxiway and the edges of various airstrips and shall not be more than 3 m away from the edges.

Runway centerline light:

Runway centerline lights are arranged along the runway centerline at a distance of about 15 m between the runway entrance and the end. On the side with less exit taxiway, deviation from the runway centerline is allowed up to 0.6 m. Only when the maintenance of the airport lights in the middle line of the runway can ensure that the integrity rate of the lamps reaches more than 95% and no two adjacent lamps fail, and the runway is planned to operate when the visual range of the runway is equal to or greater than 350 m, the longitudinal spacing of the lamps can be changed to approximately 30 m.

Runway sidelight:

Runway sideline lights shall be provided along the full length of the runway on two parallel lines equidistant from the center line of the runway, along the edge of the area declared for use as the runway or not more than 3m away from the edge. The longitudinal spacing of lamps and lanterns should be as uniform as possible. If it is an instrument runway, the spacing of lamps and lanterns should not be more than 60 m; if it is a non-instrument runway, the spacing of lamps and lanterns should not be more than 100 m. The lights on both sides of the runway should correspond one to one to form a straight line perpendicular to the runway center line.

The navigation light system is one of the important links in the normal operation of the airport, and it is an important visual navigation aid to ensure the flight safety of the aircraft. It plays an important role in the process of aircraft approach and landing. The normal operation of the navigation light system is directly related to the safety of aircraft taking off and landing. In view of the importance of the airport navigation light to the safety of aircraft taking off and landing, it is necessary to keep the equipment in normal working condition at all times.

Airport lighting is very important to the flight of the aircraft, so do not be careless, the airport in the lighting energy-saving transformation, to choose a reliable brand to do, so that there is a guarantee, is responsible for the consumer!
